M.V. AGUSTA 125S→350B+900
MAGNI
|
|
|
|
【ＥＮＧＩＮＥ】
| Type |
four stroke |
| Number of cylinders |
two |
| Disposltiom |
Side-by-side,Front of march |
| Bore and Stroke |
mm. 63X56X2 |
| Displacement |
349cc |
| Compression ratio |
1:9.5 |
| Max Horsepowe |
32CV.S.A.E Peak 7,600R.P.M |
| Comshaft |
overhead vaives operated by push rods |
| Max. Speed |
169Km/h |
| Max Torque |
Kgm.. 1.05 at 7,000 r.p.m. |
| Timing system |
rocker arms and push rods operated |
| Clutch |
multople disk in oil bath |
| Primary drive |
helical gears |
| Secondary drive |
by chain |
| Starting |
kick starter |
| Gearbox |
five speed foot operated. |
| Carburetors |
Two Dell'Orto UB24BS2 & UB24B2 |
| Exhaust system |
exhaust pipe and muffler |
| Generator |
flywheel 12V 60W |
| Ignition |
electronic |
| Lubrication |
forced by gear pump and mesh filter |
| Oil Tank |
in crankcase, containing Kg. 2 |
|
|
|
|
|
